Maximum drilling diameter Max. = 35mm (Single head) D = 13mm (Multi-head)
Maximum drilling depth H Max.=60 mm
Number of spindles 21*3=63
Drilling joint mounting hole diameter 10 mm
Maximum machining hole distance L Max.*W Max.=1500mm*640mm
Spindle speed 2840 rpm
Motor power 4.5kW
Machine dimension 3000*2500*1560 mm
Machine weight 1100 kg
Packing size 3080*1470*1750mm
