Maximum drilling diameter Max. = 35mm (Single head) D = 13mm (Multi-head)
Maximum drilling depth H Max.=60 mm
Number of spindles 22*4=88
Drilling joint mounting hole diameter 10 mm
Maximum machining hole distance L Max.*B Max.=1500mm*640mm
Spindle speed 2840 dövr/dəq
Motor power 9 kVt
Machine size 3950*2500*1560 mm
Machine weight 1450 kq
Packing size 4180*1280*1750mm
